| CPU | CPU |
Intel® LGA1700 Socket 12th/13th/14th Gen. processors
|
|
Chipset |
B760 / H610 | |
|
Processing Units |
by CPU
|
|
|
TDP |
≤ 65 W
|
|
| Memory | Size | Up to 96 GB |
| Type | 2 x SO-DIMM DDR5-5600 MHz | |
| Storage | Socket 1 |
1 x M-Key M.2 (2280) PCIe3.0 X4 for SSD
|
| Socket 2 |
1 x 2.5” SATAIII (7+15 pin)
|
|
| Display |
GPU |
Intel® UHD Graphics 730/770
|
|
Graphic Engine |
DirectX 12.0, OpenGL 4.5, OpenCL 3.0,
|
|
|
Display Interface |
1 x HDMI (Max. 4096 x 2160 @60 Hz)
1 x DP1.4 (Max. 7680 x 4320 @60 Hz)
Optional: VGA (Max. 2048 x 1536 @60 Hz) colay with DP |
|
| Network |
Network Controller
|
1 x Realtek RTL 8111H Gigabit Ethernet
1 x Intel Ethernet Controller I226-V
|
|
Ethernet Interface
|
1 x 2.5GbE RJ45, 1 x 1GbE RJ45
|
|
|
Wi-Fi/BT
|
1 x E-Key M.2 (2230) for Wi-Fi/BT, Support Wi-Fi6, Wi-Fi6E (CNVi), Wi-Fi7 (Only 14th Gen CPU)
|
|
|
Mobile Network
|
1 x B-Key M.2 (3042/3052) for 4G/5G, 1 x SIM Slot
|
|
| I/O interface |
USB(B760) |
1 x USB Type-C3.2 Gen2 (Supports DP1.4 output)
2 x USB3.2 Gen2, 2 x USB3.2 Gen1, 2 x USB2.0
|
| USB(H610) |
1 x USB Type-C3.2 Gen2 (Supports DP1.4 output)
1 x USB3.2 Gen2, 1 x USB3.2 Gen1, 4 x USB2.0
|
|
|
Serial Port |
1 x RS232
|
|
|
Audio |
1 x MIC-IN, 1 x LINE-OUT |
|
|
Button |
1 x Power on, 1 x CLR-CMOS |
|
|
Antenna |
2 x Connector for Wi-Fi/BT |
|
|
System
|
TPM
|
Optional: TPM2.0
|
|
Watchdog Timer
|
Yes
|
|
|
Auto Power On
|
Yes
|
|
|
RTC
|
Set up independently every day, a week as a cycle
|
|
|
Power Requirement
|
DC-IN, 19 V/6.32 A
|
|
|
Dimensions
|
200 mm x 185 mm x 35.5 mm (7.87” x 7.28” x 1.40”)
|
|
|
Construction
|
Metal, Black
|
|
|
Operating System
|
Windows 11 (64bit) /Linux Ubuntu (64bit) | |
|
Operating Temperature
|
0°C ~45°C (32°F~113°F) @0.7m/s Air Flow
|
|
|
Humidity
|
95% @ 45°C (non-condensing)
|
|
|
Certifications
|
CE, FCC Class B, UKCA
|
