| CPU | CPU |
AMD Ryzen7 8845HS processor |
|
Chipset |
SoC | |
|
Processing Units |
8 Cores /6 Cores |
|
|
NPU
|
AMD Ryzen AI, Overall 38 TOPS
NPU 16 TOPS AI performance
|
|
|
Configurable TDP-up |
45 W /45 W |
|
| Memory | Size | Up to 96 GB |
| Type | 2 x SO-DIMM DDR5-5600 MHz | |
| Storage | Socket 1 | 1 x M-Key M.2 (2280) for PCIe4.0 X4 SSD |
| Display |
GPU |
AMD Radeon 780M (8845HS) |
|
Multi-media |
1080p60 8bpc MPEGS/VC1, 4320p75 8bpc H.264, 4320p49 8/10bpc, H.265/VP9 decode
2160p175 8bpc H.264, 4320p43 8bpc H.265, 4320p60 8/10 bpc AV1 encode
|
|
|
Display Interface |
4 x HDMI (Max.3840 x 2160 @60 Hz) with hardware EDID
|
|
| Network |
Network Controller
|
1 x Realtek RTL8111H Gigabit Ethernet
1 x Intel® Ethernet Controller I226-V
|
|
Ethernet Interface
|
1 x 1 GbE RJ45, 1 x 2.5 GbE RJ45
|
|
|
Wi-Fi/BT
|
1 x E-Key M.2 (2230) for Wi-Fi/BT
|
|
|
Mobile Network
|
1 x B-Key M.2 (3042/3052) for 3G/4G, 1 x SIM Slot
|
|
| I/O interface |
USB |
5 x USB3.2 Gen2, 1 x USB2.0
|
|
Serial Port |
1 x RS232 DB9 (Optional: 2 x RS232)
|
|
|
Audio |
1 x MIC-IN, 1 x AUDIO-OUT
|
|
|
Button |
1 x Power on, 1 x CLR-CMOS |
|
|
Antenna |
2 x Connector for Wi-Fi/BT |
|
|
System
|
TPM
|
Optional: TPM2.0
|
|
Watchdog Timer
|
Yes | |
|
Auto Power On
|
Yes
|
|
|
RTC
|
Set up independently every day, a week as a cycle
|
|
|
Power Requirement
|
DC-IN, 19 V/4.74 A
|
|
|
Dimensions
|
205 mm x 130mm x 32mm (8.07” x 5.12” x 1.26”)
|
|
|
Construction
|
Metal, Black
|
|
|
Operating System
|
Windows 11 (64bit) /Linux Ubuntu (64bit)
|
|
|
Operating Temperature
|
0°C ~45°C (32°F~113°F) @0.7m/s Air Flow
|
|
|
Humidity
|
95% @ 40°C (non-condensing)
|
|
|
Certifications
|
CE, FCC Class B, UKCA
|
