D77 (Android)

Android 12 Player
RK3588 Inside
4 Video Output with EDID
Rockchip RK3588 Processor
Rockchip RK3588 Processor
The ultra-compact Android player is powered by Rockchip RK3588 processor, which integrates quad-core Cortex-A76 and quad-core Cortex-A55. The 8nm chip is a high-performance, low-power and cached application processor. Rockchip RK3588 integrated GPU, VPU and NPU The build-in NPU supports INT4/INT8/INT16/FP16 hybrid operation and its computing power is up to 6TOPs.
4 Display Outputs
4 Display Outputs
The player adopts ARM Mali-G610 MP4 GPU and has 4 HDMI display outputs. It supports hardware EDID and H.265/H.264/AV1/AVS2 etc. video decoder.
Supporting Android 12
Supporting Android 12
The Android 12 player can be used in a variety of applications, such as digital signage, edge computing, kiosks and other AIoT solutions.
I/O port introduction
CPU CPU

Rockchip RK3588

Frequency

2.40 GHz

Processing units

4 Cores Cortex-A76 & 4 Cores Cortex-A55
TDP

15 W

Memory

Size

8 GB,
Type Onboard 2-channel LPDDR4x
Storage Onboard
128 GB, Onboard eMMC
1 x M-key M.2 (2280) for PCIe3.0 X4 SSD (NVMe)
Network

Network Controller

1 x Realtek RTL 8211E Gigabit Ethernet

Ethernet Interface

1 x GbE RJ45

Wi-Fi/BT

1 x E-keyM.2(2230) for Wi-Fi/BT module,
Supporting Wi-Fi 5 /6

Mobile Network

1 x B-key M.2(3042) for 3G /4G
1 x SIM Slot
Display

GPU

ARM Mali-G610 MP4 GPU

Graphic Engine

OpenGL ES 1.1/2.0/3.2, OpenCL 1.1/1.2/2.0, Vulkan 1.1/1.2

Multi-Media

H.265/H.264/AV1/AVS2 etc. video decoder, up to 8K@60fps
8K@30fps video encoders for H.264/H.265

Display Interface

3 x HDMI (Max. 4096 x 2160 @60 Hz)
1 x HDMI (Max. 1920 x 1080 @60Hz)
I/O interface USB

1 x USB3.2 Gen1 (OTG), 1 x USB3.2 Gen1
2 x USB2.0

Serial Port

1 x RS232

Audio

1 x MIC-IN, 1 x AUDIO-OUT

Button

1 x Power on, 1 x Recovery

Antenna

1 x Connector for Wi-Fi/BT
1 x Connector for 3G/4G (Reserved)

System Watchdog Timer Yes
Auto Power On Yes
RTC Set up independently every day, a week as a cycle
Power Requirement DC-IN, 12 V/2.08 A
Dimensions
189.6mm x 148.3mm x 26mm (7.46” x 5.83” x 1.02”)
Construction Metal, Black
Operating System Android 12
Operating Temperature 0°C ~45°C (32°F~113°F) @0.7m/s Air Flow
Humidity 95% @ 45°C (non-condensing)
Certifications CE, FCC Class B
