| Processor | CPU | Intel® Celeron® J6412 processor Intel® Pentium® J6426 processor |
| Frequency | 2.60 GHz/3.00 GHz | |
| Chipset | SoC | |
|
Processing Units
|
4 Cores/4 Cores | |
|
TDP
|
10 W/10 W | |
| Memory | Size | 4 GB (Optional: 8 GB) |
| Type | Onboard DDR4-2666 MHz | |
| Storage | Socket1 |
1 x Full-size Mini-PCIe for MSATA
|
| Onboard | Optional: Onboard eMMC5.1 | |
| Display | GPU |
Intel® UHD Graphics
|
|
Graphic Engine
|
DirectX, OpenGL, OpenCL, Intel® Quick Sync Video
|
|
|
Display Interface
|
1 x DP (Max.3840 x 2160 @60 Hz), 1 x HDMI (Max.3840 x 2160 @60 Hz)
|
|
| Network | Network controller | 1 x Realtek RTL 8111H Gigabit Ethernet |
| Ethernet interface | 1 x RJ45 | |
| Wi-Fi/BT | 1 x E-Key M.2 (2230) for Wi-Fi/BT Support Wi-Fi 5, Wi-Fi 6 | |
| Mobile network | NA | |
| I/O interface | USB | 4 x USB3.2 Gen2 (10 Gbps) |
| Serial port | 1 x RS232 | |
| Audio | 1 x 2-IN-1 headset (MIC-IN & AUDIO-OUT) | |
| Button | 1 x Power on, 1 x CLR-CMOS | |
| Antenna | 2 x Connector for Wi-Fi/BT | |
| System |
TPM
|
Optional: TPM2.0
|
|
Watchdog Timer
|
Yes
|
|
|
Auto Power On
|
Yes | |
|
RTC
|
Set up independently every day
|
|
|
Power Requirement
|
DC-IN, 19 V/2.37 A
|
|
|
Dimensions
|
130 mm x 129.3 mm x 25.4 mm (5.12” x 5.09” x 1”)
|
|
|
Construction
|
Metal, Black
|
|
|
Fanless
|
No | |
|
Operating system
|
Windows 10 (64bit) /Windows 11 (64bit) /Linux Ubuntu (64bit)
|
|
|
Operating temperature
|
0°C ~45°C (32°F~113°F) @0.7m/s Air Flow
|
|
|
Humidity
|
95% @ 45°C (non-condensing)
|
|
|
Certifications
|
CE, FCC Class B
|
