| CPU | CPU |
Rockchip RK3328 |
| Frequency |
1.50 GHz |
|
| Processing Units | 4 Cores | |
| TDP | 6 W | |
| Memory | Size |
2 GB |
| Tpye |
Onboard DDR4-2133 MHz |
|
| Storage | Onboard | 16 GB, Onboard eMMC (Optional: 32 GB/64 GB) |
| Socket | 1 x TF Card reader | |
| Display | GPU |
Mali-450MP2 |
| Graphic Engine |
OpenGL ES1.1/2.0 |
|
| Multi-Media |
4K VP9 decoders |
|
| Display Interface |
1 x HDMI (Max.3840 x 2160 @60 Hz) |
|
| Network | Network Controller | 1 x Realtek RTL8211E PHY |
| Ethernet Interface | 1 x RJ45 | |
| Wi-Fi/BT | Onboard Wi-Fi/BT module | |
| Mobile Network | 1 x Full-size Mini-PCIe for 3G/4G 1 x SIM Slot |
|
| I/O interface | USB |
1 x USB3.2 Gen1, |
| Serial Port |
1 x RS232 |
|
| Audio |
1 x MIC-IN, 1 x AUDIO-OUT |
|
| Button |
1 x Power on, 1 x Recovery |
|
| Antenna |
1 x Connector for Wi-Fi/BT, |
|
| System |
Watchdog Timer
|
NA |
|
Auto Power On
|
Yes | |
|
RTC
|
Set up independently every day, a week as a cycle
|
|
|
Power Requirement
|
DC-IN, 12 V/2.08 A
|
|
|
Dimensions
|
116 mm x 106 mm x 30 mm (4.57” x 4.17” x 1.18”)
|
|
|
Construction
|
Metal, Black
|
|
|
Operating System
|
Android 7.1/Android 10
|
|
|
Operating Temperature
|
0°C ~40°C (32°F~104°F) @0.7m/s Air Flow
|
|
|
Humidity
|
95% @ 40°C (non-condensing)
|
|
|
Certifications
|
CE, FCC Class B
|
