| CPU | CPU |
Rockchip RK3576 processor |
|
Processing Units |
4 Cores Cortex-A72 & 4 Cores Cortex-A53 |
|
| NPU |
|
|
| TDP |
6W |
|
| Memory |
Size |
4 GB (Optional: 8 GB) |
|
Type |
Onboard LPDDR4/ LPDDR4x | |
| Storage | eMMC | 64 GB, Onboard eMMC (Optional: 128GB) |
| M.2 | Optional: 1 x M-Key M.2(2242/2280) PCle2.1 X1 for SSD | |
| Display |
GPU |
Mali-G52MC3 |
|
Graphic Engine |
OpenGL ES3.2, OpenCL2.0, Vulkan |
|
|
Multi-Media |
8K@30fps H.265/VP9/AV1/AVS2 Decoder 4K@60fps H.264/H.265 Encoder |
|
|
Display Interface |
1 x HDMI (Max. 3840 x 2160 @60 Hz) |
|
| I/O interface | USB |
3 x USB3.2 Gen1, 1x USB2.0 (OTG) |
| Serial Port | 1 x RS232 | |
|
Audio |
1 x 2-in-1 Headset (MIC-IN & AUDIO-OUT) |
|
|
Button |
1 x Power on (LED), 1 x Recovery |
|
|
Antenna |
1 x Connector for Wi-Fi/BT |
|
| Network | Network Controller | Realtek RTL8211F Gigabit Ethernet |
| Ethernet Interface | 1 x RJ45 (Supporting PoE+_IN) | |
| Wi-Fi/BT |
Onboard Wi-Fi/BT module Optional: M.2 Wi-Fi or M.2 SSD (select one) |
|
| Mobile Network | 1 x B-Key M.2(3042) for 3G/4G, 1 x SIM Slot | |
| System | Watchdog Timer | Yes |
| Auto Power On | Yes | |
| RTC | Set up independently every day, a week as a cycle | |
| Rating | 48V/0.6A，54V/0.6A（POE+） | |
| Dimensions | 160 mm x 107 mm x 36 mm（6.29″ x 4.21″ x 1.41″） | |
| Construction | Metal, Black | |
| Operating System | Android 14 | |
| Operating Temperature | 0°C ~ 45°C (32°F ~ 113°F)@0.7m/s Air Flow | |
| Humidity | 10°C ~ 90% @ 45°C (non-condensing) | |
| Certifications | CE, FCC Class B, UKCA |
