| Processor | CPU |
Rockchip® RK3568 processor
|
|
Processing Units
|
4 Cores Cortex-A55
|
|
| TDP | 6 W | |
|
Rear I/O
|
USB |
1 x USB3.2 Gen1 OTG, 1 x USB3.2 Gen1
|
|
Display Interface
|
1 x HDMI (Max.3840 x 2160 @60 Hz)
Optional: 1 x VGA (Max.1920 x 1080 @60 Hz) |
|
|
Audio
|
1 x 2-IN-1 Headset (AUDIO-OUT & MIC-IN)
|
|
| Ethernet Interface |
1 x 1 GbE RJ45
|
|
|
Button
|
1 x Power on,
|
|
|
Internal I/O
|
USB
|
9 x USB2.0, signal by 9 x 4pin USB header
1 x UBS3.2 Gen1 |
|
Display
|
2 x 10pin eDP,
2 x 15pin dual channel 24bit LVDS (Max. 1920 x 1200@24 Hz) |
|
|
Camera
|
1 x MIPI-CSI jack
|
|
|
Serial port
|
2 x RS232, signal by 2 x 4pin header,
2 x RS485, signal by 2 x 4pin header, 2 x TTL, signal by 2 x 4pin header,, |
|
|
IO
|
1 x 8pin IO-KEY, 1 x 3pin IR
|
|
|
Audio
|
1 x 2pin MIC-IN, 1 x 4pin SPK (5W)
|
|
|
Others
|
1 x 6pin TP_I2C
1 x 4pin DC_IN
1 x 6pin LVDS_BL, 1 x 6pin eDP_BL
1 x 8pin GPIO |
|
|
Network
|
Network Controller
|
1 x Realtek RTL8211E Gigabit Ethernet |
|
Wi-Fi/BT
|
Onboard Wi-Fi/BT module
|
|
|
Mobile Network
|
1 x Full-size Mini-PCIe for 3G/4G
1 x SIM Slot
|
|
| System |
GPU
|
Mali-G52
|
|
Graphic Engine
|
OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1
|
|
|
Multi-Media
|
4K 60fps H.265/H.264/VP9 decoders
1080P 60fps H.265/H.264 encoders |
|
|
System Memory
|
2 GB, Onboard DDR4, (Optional: 4 GB)
|
|
|
Storage
|
32 GB, Onboard eMMC (Optional: 64 GB),
1 x TF Card Reader |
|
|
Watchdog Timer
|
Yes | |
|
Auto Power On
|
Yes | |
|
RTC
|
Set up independently every day, a week as a cycle
|
|
|
Power Requirement
|
DC-IN, 12 V
|
|
|
Dimensions
|
146 mm x 102 mm (5.75” x 4.02”)
|
|
|
Cooling System
|
Fanless, passive cooling | |
|
Operating System
|
Android 11/Debian 10
|
|
|
Operating Temperature
|
0°C ~ 60°C (32°F ~ 140°F) @0.7m/s Air Flow
|
|
|
Storage Temperature
|
-20°C ~ 75°C (-4°F ~ 167°F)
|
|
|
Humidity
|
95% @ 60°C (non-condensing)
|
